$589.99 SHIPPED TO THE DOOR!

UPDATE: Fitment issues are not a problem.

Lowered vehicles with just simple springs such as Eibach, Steeda, FRPP, etc will need to just verify pinion angle. For precautionary purposes, there is a bolt holding the emergency brake cable up towards the rear of the driveshaft tunnel. Simply unbolt it, and move the emergency brake away from the driveshaft 1.5". That's all!

For vehicles lowered more than your typical lowering springs 2"+, you will want to do the modification above PLUS there are two spots on the driveshaft tunnel that need massaging. In the middle of the floor tunnel, there is a stamping approximately 3/4" x 4" wide. Bump this down flat using a rubber mallot, or whatever you prefer. And one last spot...Back where that emergency cable bolt was you'll find a 2" by 3/8" wide lip. Bump that up flat and you're done! Make sure you check your pinion angle too. You may need adjustable control arms. That is all! Nothing else to it!

Will not fit Saleen Short Shifter Adaptors!

These are balanced to within 1/8 of a gram, and WILL NOT VIBRATE as long as your pinion angles are correct.

The price is $589.99 shipped.






CR
Tillman Speed



Make sure you also inquire about driveshaft safety loops, we have universal ones for $32.99 with your purchase of the aluminum driveshaft. If you want something vehicle specific, we carry CHE as well!!!

CR
Tillman Speed



Just another FYI, for potential customers...

If you have installed a set of Aftermarket motor mounts, this may cause a change in the pinion angle as well.

It looks like this will turn out to be a hassle free install for most, with no changes needed to the pinion angle. However, I would recommend that everyone check the pinion angle after installing the drive shaft to insure that the tunnel is free and clear of any contact with with drive shaft.

Again, good luck on the sale Tillman. I know this will be a hot item for you guys!



Mark at Coast Driveline is a great guy, and he really knows his stuff!!

Their shop is a little more than an hour from my work.



IF anyone has contact with the driveshaft, they won't need to check the pinion angle to find out. Launch at 2800 with the stock tires and you'll know if it bangs or not



Check out the information at the top post and it will help with all clearance issues!

CR
Tillman Speed



Good luck with the Sale...



So it looks like we got everything cleared up. These driveshafts are shipping today!

CR
Tillman Speed



What's the Diameter of the shaft?

Richard



4" diameter shaft

CR
Tillman Speed



All orders have shipped, I will try and send out tracking numbers in a few! THANKS!

Anyone else who is still interested, they are still $589.99 for a limited time before they go back up to $579.99 plus shipping. That could be as much as $629 shipped!

CR
Tillman Speed



My understanding is that on lowered cars the 4" Shaft has clearance issues. How has this been resolved with this shaft? I am asking because my car is lowered.

Richard



Good luck with the Sale...



This issue was addressed up top, the first post! UPDATED!!

CR
Tillman Speed



jsut a note, im only lowered 1.5" and i had clearance issues wit ha 4" shaft. others might too. rememebr the way the car is setup from the factory isnt the same on every car. with only a 1.5" drop, i had to adjsut the pinion angle and i didnt have motor mounts or any other mods that would affect pinion angle at the time.



Additional info is here: http://forums.bradbarnett.net/showthread.php?t=60033



Tillman Speed should be BANNED !!! He is making me broke buying all his candy !! LOL

Another must buy..............



Tell me about it! I'm going to go buy an S197 just to buy all the cool stuff available for them! LOL

CR
Tillman Speed



CR This is Chris from Wheels Direct. Didnt get a tracking number yet. Once again email is 01mingreyvert@bellsouth.net



PM Sent
